When you navigate between pages on high-end editorial portfolios, the transition rarely feels like a traditional webpage loading. Instead of a jarring hard-cut or an uninspired opacity crossfade, the outgoing page physically retreats — shrinking down, drifting south, and tilting slightly off-axis — while the incoming view sweeps across from the bottom-right corner through an angled, expanding diagonal slice.

It creates a tactile sensation of depth and physical momentum, reminiscent of sliding photography boards across an architect's desk.

We recently packaged this transition into two complementary forms in the Sora ecosystem:

The Component Pattern: TiltSlideTransition — an interactive, self-contained layout showcase with GSAP SplitText character and line reveals, Lenis smooth scrolling, and controlled view switching.
The App Router Architecture: tilt-slide-template — a standalone, multi-page Next.js template using React 19's native <ViewTransition> component in template.tsx.

Here is the complete teardown of how the animation works, the mathematics of the CSS keyframes, and how to implement it both as a contained component and across real multi-page Next.js routes.

What makes the transition feel so natural?

The secret to this effect isn't just movement; it's choreographed asymmetry.

Most multi-page transitions apply symmetric easing: Page A slides left by 100%, Page B enters from the right by 100% at the exact same velocity. The result often feels mechanical.

In the tilt-slide transition, two distinct spatial transformations happen on an offset timeline:

Transition Layer	Start Time	Duration	Key Motion Behavior
Outgoing (`page-out`)	`0.00s`	`1600ms`	Scales down to `0.8` → tilts `-10°` → drifts down-left (`-50%, 20%`)
Incoming (`page-in`)	`+0.25s` (delay)	`1500ms`	Expands diagonal `clip-path` from bottom-right → slides to `(0, 0)`
Navbar (Anchor)	Continuous	Persistent	Remains fixed and un-animated via `view-transition-name: navbar`

The 3-Phase Choreography

Phase 1: Depth Squeeze (0.00s → 0.25s)
The active page scales down to 80% while staying level (rotate(0deg)). This gives the viewer's eye an instant cue that the current plane is receding in 3D space.
Phase 2: The Offset Slice (+0.25s)
After a deliberate 250ms delay, the incoming page cuts in from the bottom-right quadrant using an angled diagonal clip-path.
Phase 3: Tilt & Full Reveal (0.25s → 1.75s)
While the outgoing page tilts -10° and slides out of frame, the new page expands to 100% viewport coverage and settles cleanly into place.

Deep Dive: The CSS Keyframe Mechanics

All the motion lives in standard CSS pseudo-elements provided by the browser's View Transition API:

::view-transition-group(navbar) {
  animation: none;
  z-index: 100;
}

::view-transition-old(.page-exit),
::view-transition-old(page-content) {
  animation: 1600ms cubic-bezier(0.65, 0, 0.35, 1) both page-out;
}

::view-transition-new(.page-enter),
::view-transition-new(page-content) {
  animation: 1500ms cubic-bezier(0.65, 0, 0.35, 1) both page-in;
  animation-delay: 0.25s;
}

The Outgoing Squeeze & Tilt

@keyframes page-out {
  0% {
    transform: translateX(0%) translateY(0%) rotate(0deg) scale(1);
    opacity: 1;
  }
  40% {
    transform: translateX(0%) translateY(0%) rotate(0deg) scale(0.8);
    opacity: 0.5;
  }
  100% {
    transform: translateX(-50%) translateY(20%) rotate(-10deg) scale(0.65);
    opacity: 0.25;
  }
}

Notice the midpoint keyframe at 40%:

The element shrinks to 80% scale while remaining level at rotate(0deg). This gives the eye time to register that the current canvas is moving back in 3D space.
Between 40% and 100%, it accelerates into a -10deg counter-clockwise tilt and sinks down 20% on the Y-axis.

The Diagonal Polygon Slice

The entrance uses CSS clip-path: polygon(...) to create an angular reveal:

@keyframes page-in {
  from {
    transform: translateX(100%) translateY(20%);
    clip-path: polygon(50% 50%, 100% 50%, 100% 100%, 50% 100%);
  }
  to {
    transform: translateX(0%) translateY(0%);
    clip-path: polygon(0% 0%, 100% 0%, 100% 100%, 0% 100%);
  }
}

At the from frame:

The polygon polygon(50% 50%, 100% 50%, 100% 100%, 50% 100%) isolates the bottom-right quadrant.
Combined with translateX(100%) translateY(20%), the incoming page bursts out of that lower right quadrant and expands diagonally to cover polygon(0% 0%, 100% 0%, 100% 100%, 0% 100%).

Because both pseudo-elements run hardware-accelerated transforms and clip-paths, this animation executes comfortably at 60-120fps without dropping frames.

Pattern 1: Standalone Component (`document.startViewTransition`)

If you are building an interactive showcase, catalog item, or single-page dashboard where views change within a container, you can trigger native View Transitions imperatively using document.startViewTransition:

"use client";

import { useCallback, useRef, useState } from "react";
import { flushSync } from "react-dom";

export function TiltSlideShowcase() {
  const [activePage, setActivePage] = useState<"home" | "projects" | "info">("home");
  const isTransitioningRef = useRef(false);

  const handleNavigate = useCallback((targetPage: typeof activePage) => {
    if (targetPage === activePage || isTransitioningRef.current) return;

    if (typeof document !== "undefined" && "startViewTransition" in document) {
      isTransitioningRef.current = true;
      try {
        const transition = document.startViewTransition(() => {
          // flushSync ensures React updates DOM state synchronously
          // before the browser captures the "new" snapshot
          flushSync(() => {
            setActivePage(targetPage);
          });
        });

        transition.finished.finally(() => {
          isTransitioningRef.current = false;
        });
      } catch {
        setActivePage(targetPage);
        isTransitioningRef.current = false;
      }
    } else {
      // Fallback for browsers without View Transition API
      setActivePage(targetPage);
    }
  }, [activePage]);

  return (
    <div className="tst-root">
      <nav style={{ viewTransitionName: "navbar" }}>
        <button onClick={() => handleNavigate("home")}>Home</button>
        <button onClick={() => handleNavigate("projects")}>Projects</button>
        <button onClick={() => handleNavigate("info")}>Info</button>
      </nav>

      <div
        className="page-content page-enter page-exit"
        style={{ viewTransitionName: "page-content" }}
      >
        {activePage === "home" && <HomeView />}
        {activePage === "projects" && <ProjectsView />}
        {activePage === "info" && <InfoView />}
      </div>
    </div>
  );
}

[!IMPORTANT] Why flushSync is critical: React 18 and 19 batch state updates asynchronously. document.startViewTransition(callback) expects the DOM to reflect the new state immediately when callback() resolves so it can snapshot the new view. Wrapping setActivePage inside flushSync guarantees that the DOM updates synchronously.

Pattern 2: Next.js App Router Multi-Page Template (`<ViewTransition>`)

In a real multi-page application with separate routes (/, /projects, /about, /info), you don't want a fake tab switcher. You want real URLs, SEO, browser back/forward history, and prefetching.

In Next.js 15+ and React 19, you can orchestrate this across genuine route changes using template.tsx and React's experimental <ViewTransition>:

1. The Template Wrapper (`src/app/template.tsx`)

Unlike layout.tsx (which persists across navigations), template.tsx remounts on every route change. This makes it the ideal place to assign the transition tags:

"use client";

import type { ReactNode } from "react";
import { ViewTransition } from "react";

export default function Template({ children }: { children: ReactNode }) {
  return (
    <ViewTransition enter="page-enter" exit="page-exit" default="none">
      {children}
    </ViewTransition>
  );
}

2. The Persistent Layout (`src/app/layout.tsx`)

Your navigation bar sits inside layout.tsx and maintains a permanent identity:

import type { ReactNode } from "react";
import Navbar from "@/components/Navbar";
import "./globals.css";

export default function RootLayout({ children }: { children: ReactNode }) {
  return (
    <html lang="en">
      <body>
        <Navbar />
        {children}
      </body>
    </html>
  );
}

Assigning viewTransitionName: "navbar" tells the browser: "Do not snapshot or animate me as part of the page content. Keep me fixed in place."

import Link from "next/link";

export default function Navbar() {
  return (
    <nav className="navbar" style={{ viewTransitionName: "navbar" }}>
      <Link href="/">Home</Link>
      <Link href="/projects">Projects</Link>
      <Link href="/about">About</Link>
      <Link href="/info">Info</Link>
    </nav>
  );
}

Now, clicking any <Link href="..."> triggers the native browser View Transition automatically. Zero client routing hacks, zero heavy third-party routing wrappers.

The Mobile & Responsive Footgun: Viewport Scroll Locking

When adapting this transition to responsive viewports, a common bug occurs:

/* ❌ Problem: The container clips overflowing content */
.tst-root {
  height: 100svh;
  overflow: hidden;
}

On desktop, your pages might fit neatly inside 100svh. But on mobile viewports:

Two-column layouts collapse into a vertical stack (flex-direction: column).
Images take vertical room (55vh), pushing text down.
The total height exceeds 100svh.

If your sub-views don't have their own scroll container, users will find the page locked and unable to scroll down.

To fix this cleanly:

Give each sub-view height: 100svh; overflow-y: auto;.
Wrap scrollable columns in a smooth scroll container like ReactLenis:

export function InfoView({ image, paragraph }: InfoProps) {
  return (
    <ReactLenis className="info" options={{ wrapper: undefined }}>
      <div className="info-container">
        <div className="col">
          <img alt="Portrait" src={image} />
        </div>
        <div className="col">
          <p>{paragraph}</p>
        </div>
      </div>
    </ReactLenis>
  );
}

.tst-root .info {
  width: 100%;
  height: 100svh;
  overflow-y: auto;
  background-color: var(--bg);
}

.tst-root .info-container {
  width: 100%;
  min-height: 100svh;
  display: flex;
}

@media (max-width: 1000px) {
  .tst-root .info-container {
    flex-direction: column;
    min-height: 100svh;
  }
  .tst-root .col:first-child {
    height: 55vh;
    min-height: 300px;
    flex: none;
  }
  .tst-root .col:nth-child(2) {
    padding: 2.5rem 1.5rem 5rem;
    flex: none;
  }
}

Now, on both mobile screens and narrow split-screen preview panels, visitors can smoothly scroll all the way to the bottom without breaking the transition.

Resources & Starter Template

You can explore and fork the ready-to-use template or try the component in Sora UI:

Live Template Demo: tilt-slide-template.soralabs.studio
GitHub Starter Repository: SoraLabsOSS/tilt-slide-template
Sora UI Component: Tilt Slide Transition

# Clone the complete Next.js starter
git clone https://github.com/SoraLabsOSS/tilt-slide-template.git my-portfolio
cd my-portfolio
bun install
bun dev

Credits

Inspired by the editorial portfolio transition on Paul Kalkbrenner and the multi-page View Transition technique demonstrated by Codegrid. Reimplemented natively for React 19, TypeScript, and Next.js App Router.
